PTAT series electric actuator is with unique design, It can be used to control the 0 ° ~ 270 ° rotary valve or and other similar products, such as butterfly valve, ball valve, air valve, flapper valve, plug valve, louver valve, etc. It can be widely used in petroleum, chemical industry, water...
| Quantity: | |
|---|---|
PTAT series electric actuator is with unique design, It can be used to control the 0 ° ~ 270 ° rotary valve or and other similar products, such as butterfly valve, ball valve, air valve, flapper valve, plug valve, louver valve, etc. It can be widely used in petroleum, chemical industry, water treatment, shipping, paper making, power station, heat supply, building automation, light industry and other areas. .With ac 380v/220v/110v driving power supply, the actuator can make the valve movement to the required position by 4-20 ma current signal or 0 to 10 v DC voltage controlling signal. The maximum output torque is 4000 N·M.
Input Voltage | |||||
DC24V | AC24V | AC110V | AC220V | AC380V | |
Motor Power | 30W | ||||
Rated Current | 2.4A | 3A | 0.64A | 0.28A | 0.19A |
Output Torque | 100NM | 50NM/60NM/100NM | |||
Operating Time | 10S | 5S/30S/40S | |||
Output Shaft | Square hole：14*14/17*17，Depth：18/32； | ||||
Control Circuit | B-type/S-type/R-type/H-type/A-type/K-type/D-type/T-type/ | ||||
Operation Angle | 0~270° | ||||
Weight | 4.7kg | ||||
Dielectric Strength | 500VAC/Minute | 1500VAC/Minute | |||
Insulation Resistance | 100MΩ/300VDC | 100MΩ/500VDC | |||
Working Temperature | -25°C~60°C | ||||
Installation Angle | 360° Any Angle | ||||
Housing | Aluminium Alloy Die-castings，IP67 water-proof grade，NEMA4and6 | ||||
Optional Function | Over torque Protection、Heat Dehumidifier | ||||
Ball Valve | 15-65 | ||||
Butterfly Valve | 50-100 | ||||
DIN cast iron ball valve
The valve design and manufacturing: DIN3357-1
Flange drilling: DIN2542
Face to Face: DIN3202 F4
Pressure Test: DIN3230-3
1. valve body:CF8
2. Bonnet: CF8
3. Nut:304
4. Bolt:304
5. Seal ring:PTFE
6. Ball:304
7. Gasket:PTFE
8. Stem:304
9. Packing:PTFE
10. Gland cap: CF8
11. Yolk: 304
12. Hex nut:304
